Instrumentation Tube Fittings — Saudi Arabia

Instrumentation Tube Fittings Supplier — Saudi Arabia

By Gulf Union Ozone Technical & Procurement Team ·

Gulf Union Ozone Trading Co. supplies Parker A-LOK® and CPI™ instrumentation tube fittings — straight connectors, elbows, tees, unions, bulkheads, reducers, crosses, plugs, and caps — in SS 316/316L, duplex 2205, brass, and carbon steel, stocked in Jeddah, Saudi Arabia. Parker brand fittings are supplied with EN 10204 3.1 Material Test Certificates and Certificates of Conformance. Tube OD range: 1/8" to 1" imperial; 6mm to 25mm metric. Swagelok-compatible dimensions. SAEP-347 compliant materials. SAES-J-003 compatible. NACE MR0175 / ISO 15156 sour-service duplex grades available. ISO 9001:2015 certified, CR 4030570569. Same-day dispatch from our Jeddah Parker-authorized warehouse to Aramco, SABIC, SWCC, and EPC projects across the Kingdom.

Submit RFQ
Parker A-LOK and CPI instrumentation tube fittings stocked in Jeddah Saudi Arabia — Gulf Union Ozone
BrandParker A-LOK® & CPI™
MaterialsSS 316/316L · Duplex 2205 · Brass
Sizes1/8" – 1" Imperial · 6–25mm Metric
DispatchSame-day Jeddah · 48–72h Jubail
DocsEN 10204 3.1 MTCs · CoC · PMI
Fitting Categories

Product Types in Stock

Gulf Union Ozone maintains safety stock across the Parker A-LOK® and CPI™ instrumentation tube fitting range, plus push-to-connect and sour-service duplex grades, all supplied with full EN 10204 3.1 mill documentation for Saudi Aramco and SABIC project requirements.

Type 01

Parker A-LOK® Straight & Elbow Connectors

Parker A-LOK® double-ferrule compression fittings for instrument tubing — straight male connectors (tube-to-NPT and tube-to-BSP), female connectors, tube-to-tube unions, and 90° and 45° elbows in SS 316/316L. Tube OD 1/8" through 1" imperial; 6mm through 25mm metric. A-LOK front cutting ferrule bites into tube OD while back ferrule provides axial spring force — maintaining a leak-tight seal through thermal cycling and vibration. Working pressure up to 10,000 psi (689 bar) in 1/4" SS tube. ASTM A479 SS 316/316L body material. ASME B1.20.1 NPT threads. EN 10204 3.1 MTCs and CoCs supplied with every order. SAEP-347 compatible grade.

■ SAEP-347
Type 02

Parker A-LOK® Tees, Unions, Crosses & Reducers

Parker A-LOK® equal tees, reducing tees, union crosses, in-line unions, reducing unions (1/4" to 3/8" and 1/2" to 1/4"), bulkhead unions for panel penetrations, and male elbow connectors. All in SS 316/316L. Bulkhead unions allow instrument tubing to pass cleanly through enclosure walls — most common in analyser sample conditioning cabinets and marshalling panels at Saudi Aramco instrumentation rooms. Reducing unions allow size transitions in instrument manifold headers without additional adapters. End caps and plugs for dead-ending impulse lines during commissioning and testing. All items carry full EN 10204 3.1 MTCs traceable to originating mill heat number.

■ SAEP-347
Type 03

Parker CPI™ Compression Fittings

Parker CPI™ (Compression, Pre-swaged Instrumentation) fittings offer a single-ferrule compression design and are widely used alongside A-LOK systems for general instrument tubing connections. CPI female connectors (tube-to-FNPT), male connectors (tube-to-MNPT), equal tees, branch tees with FNPT off-take, and unions are stocked in SS 316/316L and brass. Brass CPI fittings serve non-process instrumentation such as air systems, water utility lines, and general-service pneumatic control. SS 316/316L CPI fittings are used for corrosive and process-fluid instrument lines where a cost-competitive alternative to A-LOK double-ferrule is acceptable. Dimensions conform to ASTM A479 material and ASME B1.20.1 NPT thread standards.

■ SAEP-347
Type 04

Parker Push-Lok & PushTite Push-to-Connect

Parker Push-Lok and PushTite push-to-connect fittings for pneumatic instrument air tubing — nylon, polyurethane, and PTFE tube OD 4mm to 16mm (metric) and 1/8" to 1/2" (imperial). One-touch tube insertion with collet-grip release tool for fast installation in pneumatic control panels, valve positioner signal tubing, and instrument air distribution headers. SS 316 and nickel-plated brass body options. Maximum working pressure: 10 bar (145 psi) at 20°C. Temperature range: -20°C to +80°C. Types include straight unions, 90° elbows, tees, Y-fittings, reducers, and bulkhead variants. Used at Saudi Aramco and SABIC for positioner air supply tubing and pneumatic control panel assembly.

Type 05

Duplex 2205 Sour-Service Tube Fittings

Double-ferrule compression tube fittings in duplex stainless steel 2205 (UNS S31803/S32205) for instrument tubing systems in sour-service environments requiring NACE MR0175 / ISO 15156 compliance. Duplex 2205 offers a PREN (pitting resistance equivalent number) of approximately 35 versus 24 for SS 316L — providing significantly superior resistance to sulphide stress cracking and pitting in H₂S-containing process streams. Required for instrument impulse lines on sour-gas separators, H₂S-containing crude systems, amine absorbers, and sour water strippers at Saudi Aramco and SABIC facilities. Hardness ≤ HRC 22 per ISO 15156-3. Supplied with NACE MR0175 compliance statements and EN 10204 3.1 MTCs confirming duplex grade chemistry. Available by inquiry — typical 5–10 working day lead time.

Type 06

Carbon Steel & Brass Fittings for Non-Process Instrumentation

Carbon steel double-ferrule compression fittings for hydraulic instrument lines and non-process tubing systems where stainless steel is not required — pressure gauge sensing lines on lube oil systems, hydraulic control systems on valves, and instrument air distribution where fluid compatibility allows carbon steel. Brass compression fittings (CPI and A-LOK equivalent) for non-process instrumentation — instrument air, cooling water sensing, and general utility gauge connections where ambient service conditions and non-corrosive media allow brass body and ferrule material. All brass fittings comply with ASTM B124 material standard. Carbon steel fittings supplied with EN 10204 2.2 certificates; SS and brass with EN 10204 3.1. PMI available on request for all grades.

In Summary

Instrumentation tube fittings are mechanical compression connectors that form a repeatable, leak-tight seal on stainless steel instrument tubing without welding. Parker A-LOK® double-ferrule compression fittings in SS 316/316L have become the dominant specification at Saudi Aramco facilities because of their proven performance in impulse line service: a front cutting ferrule bites into the tube OD while a back ferrule provides axial spring force, maintaining seal integrity through thermal cycling and vibration. The 316L grade satisfies SAES-J-003 requirements for corrosion resistance in process instrumentation environments across the Kingdom's oil, gas, and petrochemical plants. Parker A-LOK fittings are listed in Saudi Aramco Approved Vendor Lists for instrumentation components and are interchangeable with Swagelok-dimensioned hardware already installed on operating plants, allowing mixed-lot maintenance without full replacement of tubing runs. Working pressures reach 10,000 psi (689 bar) in 1/4" OD tubing.

Product Catalog

Parker Instrumentation Tube Fittings — Stock Range

All items stocked in Jeddah. EN 10204 3.1 MTCs and CoCs supplied with every order. Contact us for part numbers, quantities, and lead times. Swagelok-compatible dimensions available across A-LOK and CPI series.

Product Standard / Spec Material Size Range Application
Parker A-LOK Male Connector — 4A-HC4-S4 ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 1/4" OD tube × 1/4" MNPT Tube-to-NPT connections on transmitters, gauges, and valves
Parker A-LOK Male Connector — 6A-HC6-S4 ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 3/8" OD tube × 3/8" MNPT 3/8" impulse line connections on instrument manifolds
Parker A-LOK Male Connector — 8A-HC8-S4 ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 1/2" OD tube × 1/2" MNPT 1/2" tube-to-valve NPT inlet connections
Parker A-LOK Female Connector — 4A-FH4-S4 ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 1/4" OD tube × 1/4" FNPT Tube to FNPT port connection on instrument tapping points
Parker A-LOK Reduced Male Connector — 4A-HC2-S4 ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 1/4" OD tube × 1/8" MNPT Small-port connections on pressure gauges and switches
Parker A-LOK Union — 4A-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 1/4" OD tube Instrument tubing in-line union; 10,000 psi WP
Parker A-LOK Union — 6A-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 3/8" OD tube Process instrument tubing inline connection
Parker A-LOK Union — 8A-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 1/2" OD tube Analyzer sample systems; high-flow instrument lines
Parker A-LOK Union — 12A-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 3/4" OD tube High-flow instrument headers and utility connections
Parker A-LOK Union — 16A-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 1" OD tube Larger instrument and process line connections
Parker A-LOK 90° Elbow — 4A-E4-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 1/4" OD tube Direction changes in 1/4" SS instrument tubing runs
Parker A-LOK 90° Elbow — 6A-E6-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 3/8" OD tube Direction changes in 3/8" SS instrument tubing runs
Parker A-LOK Male Elbow — 4A-ME4-S4 ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 1/4" OD tube × 1/4" MNPT Right-angle NPT to tube connection at instruments
Parker A-LOK Equal Tee — 4A-T4-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 1/4" OD tube × 1/4" OD tube × 1/4" OD Branch connections in 1/4" SS instrument tubing
Parker A-LOK Equal Tee — 6A-T6-S4 ASTM A479 SS 316; ASME B1.20.1 SS 316/316L 3/8" OD tube Branch connections in 3/8" SS instrument tubing
Parker A-LOK Bulkhead Union — 4A-BU4-S4 ASTM A479 SS 316 SS 316/316L 1/4" OD tube Panel and enclosure wall penetrations for instrument tubing
Parker A-LOK Bulkhead Union — 8A-BU8-S4 ASTM A479 SS 316 SS 316/316L 1/2" OD tube 1/2" tube panel penetrations in process enclosures
Parker A-LOK Tube End Cap — 4A-CAP-S4 ASTM A479 SS 316 SS 316/316L 1/4" OD tube Dead-ending 1/4" instrument tubing during commissioning
Parker A-LOK Reducing Union — 4A-PC6-S4 ASTM A479 SS 316 SS 316/316L 1/4" OD to 3/8" OD Tube-size transitions in instrument tubing runs
Parker A-LOK Reducing Union — 8A-PC4-S4 ASTM A479 SS 316 SS 316/316L 1/2" OD to 1/4" OD Size transition from 1/2" header to 1/4" branch runs
Parker CPI Female Connector — 4-4 FBSZ ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 1/4" OD tube × 1/4" FNPT Corrosive service female NPT tube connections
Parker CPI Female Connector — 4-4 FBZ ASTM B124 Brass; ASME B1.20.1 NPT Brass (CuZn39Pb3) 1/4" OD tube × 1/4" FNPT General utility female NPT instrument connections
Parker CPI Male Adapter — 4-4 MBZ ASTM A479 SS 316; ASME B1.20.1 NPT SS 316/316L 1/4" OD tube × 1/4" MNPT Tube-to-MNPT interface in CPI systems
Parker CPI Equal Tee — 4-4-4 TB-SS ASTM A479 SS 316 SS 316/316L 1/4" OD all three ends Three-way branch in SS CPI instrument tubing systems
Parker A-LOK Union — 6MM-S4 (Metric) ASTM A479 SS 316 SS 316/316L 6mm OD tube Metric instrument tubing — DCS/SCADA and EPC projects
Parker A-LOK Union — 10MM-S4 (Metric) ASTM A479 SS 316 SS 316/316L 10mm OD tube 10mm metric instrument tubing connections
Parker A-LOK Male Connector — 6MM-HC6-S4 (Metric) ASTM A479 SS 316; ISO 228-1 BSPT SS 316/316L 6mm OD tube × 1/4" MNPT or BSP Metric tube to NPT/BSP port connections
Duplex 2205 Compression Union — 4A type, 1/4" OD ASTM A479 UNS S31803; NACE MR0175 / ISO 15156 Duplex SS 2205 (S31803/S32205) 1/4" OD tube; HRC ≤22 Sour-service instrument impulse lines — H₂S environments
Duplex 2205 Male Connector — 4A type, 1/4" OD × 1/4" MNPT ASTM A479 UNS S31803; NACE MR0175 / ISO 15156; ASME B1.20.1 Duplex SS 2205 (S31803/S32205) 1/4" OD tube × 1/4" MNPT; HRC ≤22 Sour-service tube-to-transmitter connections
Parker A-LOK Front Ferrule — 4A-F4-S4 ASTM A479 SS 316 SS 316/316L 1/4" OD tube Replacement front ferrule for A-LOK fittings
Parker A-LOK Back Ferrule — 4A-B4-S4 ASTM A479 SS 316 SS 316/316L 1/4" OD tube Replacement back ferrule for A-LOK fittings
Parker A-LOK Compression Nut — 4A-N4-S4 ASTM A479 SS 316 SS 316/316L 1/4" OD tube Replacement nut for Parker A-LOK assemblies
In Summary

Saudi Aramco Engineering Standard SAES-J-003 (Instrumentation System Design) is the primary specification governing material selection for instrument tubing systems across all Aramco-operated facilities. It mandates 316L stainless steel seamless tubing to ASTM A269 for all process impulse lines, with double-ferrule compression fittings specifying a minimum wall thickness appropriate to the system design pressure and SAEP-347 inspection class. Instrument tubing sizes most frequently called up under SAES-J-003 are 1/4" OD × 0.035" wall for general impulse duty and 3/8" OD × 0.049" for heavier-flow sample conditioning lines. SAES-L-350 covers tube and fitting material selection for specific process fluid categories. Gulf Union Ozone stocks Parker A-LOK fittings that meet the dimensional and material requirements of SAES-J-003 and can supply full EN 10204 3.1 MTCs showing chemical composition, tensile data, and hydrostatic test results — the documentation package required at Saudi Aramco instrument inspection gates.

Technical Specifications

Parker A-LOK Tube Fittings — Working Pressures & Standards

Material grades, pressure ratings, applicable standards, and compatible tube sizes for the Parker A-LOK® and CPI™ instrumentation tube fitting inventory stocked by Gulf Union Ozone in Jeddah, Saudi Arabia.

Parker A-LOK Working Pressures — SS 316 Tube

Tube OD × Wall Max WP (psi) Max WP (bar)
1/8" × 0.028" 10,000 689
1/4" × 0.035" 10,000 689
3/8" × 0.049" 8,700 600
1/2" × 0.065" 8,000 552
5/8" × 0.065" 6,600 455
3/4" × 0.065" 5,600 386
1" × 0.083" 5,400 372

Standards & Compliance

Standard Scope
ASTM A479 SS 316/316L bar and shapes for fittings body material
ASME B1.20.1 NPT thread dimensions and tolerances
ASTM A269 Seamless SS 316/316L instrumentation tubing (companion product)
ASME B16.28 Butt-weld instrument connections (where applicable)
NACE MR0175 / ISO 15156 Sour-service requirements for duplex 2205 fittings
SAES-J-003 Saudi Aramco instrumentation system design — material selection
SAES-L-350 Saudi Aramco instrument tube and fitting selection by fluid type
EN 10204 3.1 Mill Test Certificate — third-party inspection body verification
ISO 9001:2015 Gulf Union Ozone QMS (CR 4030570569)

Tube OD Range Stocked

Imperial OD Metric OD
1/8" 6mm
1/4" 8mm
3/8" 10mm
1/2" 12mm
5/8" 14mm
3/4" 18mm
1" 25mm
In Summary

For instrument tubing systems in sour-service environments — wells producing H₂S above NACE MR0175 thresholds — 316L stainless steel compression fittings are still widely used on impulse lines but the fitting and tubing combination must demonstrate compliance with ISO 15156-3 to avoid sulphide stress cracking. For higher H₂S partial pressures, particularly in wet-gas separators and gas-injection systems, duplex stainless steel 2205 (UNS S31803/S32205) offers significantly superior resistance to pitting and stress corrosion cracking compared to 316L, with a PREN of approximately 35 versus 24 for standard 316L. Gulf Union Ozone can source duplex 2205 Parker-compatible tube fittings and ASTM A789/A790 duplex seamless tubing for sour-service instrument runs on request. All sour-service material is supplied with NACE MR0175 / ISO 15156 compliance statements and EN 10204 3.1 MTCs confirming hardness below HRC 22.

Saudi Aramco Compliance

SAEP-347 Compatible Instrumentation Tube Fittings

Gulf Union Ozone maintains safety stock of Parker A-LOK® and CPI™ fittings and SS 316/316L seamless tubing meeting the material specifications referenced in Saudi Aramco SAEP-347 for instrument tubing connections — the same material basis as SAES-J-003 impulse line systems throughout Aramco facilities.

Applications at Saudi Aramco, SABIC & SWCC

  • ✔ Pressure transmitter impulse lines — 1/4" OD SS 316L tubing with A-LOK fittings connecting process tapping points to DP and gauge transmitters throughout Aramco facilities
  • ✔ Thermowell connections and temperature element impulse lines at process vessel nozzle connections
  • ✔ Flow measurement manifolds — 5-valve and 3-valve manifold connections to orifice plates and differential pressure transmitters
  • ✔ Sample conditioning systems (GC analyser sample loops) — 3/8" and 1/2" OD SS tubing with CPI and A-LOK fittings throughout sample panels
  • ✔ Hydraulic control systems on valves — hydraulic actuation tubing headers using 3/8" and 1/2" OD tube with A-LOK or JIC fittings
  • ✔ Chemical injection tubing headers — corrosion inhibitor, scale inhibitor, and biocide injection lines using SS 316L tube and A-LOK fittings to resist chemical attack
SAEP-347 Explained →
30+
SKUs In Stock
7
Tube OD Sizes
3.1
EN 10204 MTCs
0
Days Handling (In-Stock)

Parker A-LOK® and CPI™ instrumentation tube fittings stocked in Jeddah with full EN 10204 3.1 MTCs, CoCs, and PMI on request. SAEP-347 and SAES-J-003 compatible. ISO 9001:2015 certified — CR 4030570569.

FAQ

Instrumentation Tube Fittings — Frequently Asked Questions

What Parker instrumentation tube fitting series do you stock in Saudi Arabia?

Gulf Union Ozone stocks Parker A-LOK® double-ferrule compression fittings and Parker CPI™ compression fittings from our Jeddah warehouse. The A-LOK® series covers the full range of instrumentation tube configurations — unions, 90° elbows, 45° elbows, equal and reducing tees, male and female NPT/BSP connectors, bulkhead unions, end caps, crosses, and reducing unions — in SS 316/316L and brass, tube OD 1/8" through 1" imperial and 6mm through 25mm metric. The CPI™ series provides pre-swaged compression fittings compatible with standard compression tubing systems. We also stock Parker Push-Lok and PushTite push-to-connect fittings for pneumatic instrument air tubing. All Parker fittings are supplied with EN 10204 3.1 MTCs and Certificates of Conformance. Same-day dispatch from our Jeddah warehouse for in-stock A-LOK and CPI sizes. See also our full Parker fittings and SS tube range.

Are your tube fittings compatible with SAES-J-003 Saudi Aramco instrument tubing requirements?

Yes. Parker A-LOK® and CPI™ compression fittings stocked by Gulf Union Ozone are manufactured from SS 316/316L to ASTM A479 — the material grade specified in Saudi Aramco SAES-J-003 for instrument tubing compression fittings. The fitting dimensions conform to the double-ferrule compression standard required for impulse line systems under SAES-J-003 and SAES-L-350. We supply EN 10204 3.1 MTCs and Certificates of Conformance with every order, providing the documentation required at Saudi Aramco instrument inspection gates. SAEP-347 compatibility is maintained — SS 316/316L tube fittings appear on the SAEP-347 material list for instrumentation. If your project specification calls for a specific Parker A-LOK part number or equivalent, please share your material requisition and we will confirm availability and documentation package within 2 hours. Learn more about SAEP-347 compliance.

Do you supply duplex stainless steel tube fittings for sour-service applications?

Yes. Gulf Union Ozone can supply duplex stainless steel 2205 (UNS S31803/S32205) Parker-compatible double-ferrule compression fittings for sour-service instrument tubing systems requiring compliance with NACE MR0175 / ISO 15156. Duplex 2205 fittings are specified for instrument impulse lines in high-H₂S environments such as sour-gas separators, gas-injection manifolds, and amine treating units where 316L stainless steel may be susceptible to sulphide stress cracking. Hardness is controlled to HRC 22 maximum as required by ISO 15156-3. Supply includes NACE MR0175 compliance statements and EN 10204 3.1 MTCs with chemical composition confirming chromium, nickel, and molybdenum content. Lead time for duplex tube fittings is typically 5–10 working days. Please send your RFQ with tube OD, fitting type, and service conditions for a prompt quotation. See also our duplex stainless steel product range.

What is the delivery lead time for instrumentation tube fittings to Jubail and Dammam?

For standard Parker A-LOK® and CPI™ instrumentation tube fittings in SS 316/316L, our delivery lead times from Jeddah warehouse are: Jeddah city — same day for orders confirmed before 12:00 KST; Jubail and Dammam — 48 to 72 hours; Al Khobar — 72 hours; Yanbu — 72 hours; Riyadh — 72 to 96 hours. All in-stock fittings are available for same-day dispatch with EN 10204 3.1 MTCs and Certificates of Conformance. For urgent shutdowns or turnaround requirements at Eastern Province facilities (Jubail, Ras Tanura, Dhahran, Abu Ali), please contact us by WhatsApp for current stock confirmation and fastest available dispatch. Bulk project orders for Aramco, SABIC, and EPC contractors are accommodated from safety stock, with lot traceability and project documentation packages prepared to match your MR requirements.

In Summary

Gulf Union Ozone holds Parker-authorized warehouse stock of A-LOK® and CPI™ compression fittings in Jeddah, covering the complete size range from 1/8" to 1" OD in 316/316L stainless steel. No import lead time: fittings in standard sizes are despatched same day to Jeddah customers, 48–72 hours to Jubail, Dammam, and Ras Tanura on the Eastern Province — the locations where most Saudi Aramco and SABIC instrumentation projects are executed. Yanbu customers receive delivery within 72 hours from our Jeddah warehouse; Riyadh within 72–96 hours. Every Parker A-LOK and CPI fitting is supplied with an EN 10204 3.1 Material Test Certificate covering chemical composition, mechanical properties, and conformance to ASTM A479 material specification for SS 316/316L. Certificates of Conformance (CoCs) and packing lists with heat numbers are included as standard. PMI (XRF) verification reports are available on request for project-critical orders requiring full alloy traceability.

Why Choose Us

Why Industrial Buyers in Saudi Arabia Choose Gulf Union Ozone for Instrumentation Tube Fittings

⚡

Parker Brand — Saudi Authorized Stock

Parker A-LOK® and CPI™ fittings from our Jeddah warehouse — no import wait time, genuine Parker brand recognized by Saudi Aramco, SABIC, and EPC inspection teams. Same-day dispatch on all in-stock sizes.

📄

EN 10204 3.1 Documentation Ready

Every Parker fitting order includes EN 10204 3.1 MTCs tracing to mill heat numbers, Certificates of Conformance QC-manager signed, and packing lists with lot numbers. PMI (XRF) reports available on request for Saudi Aramco inspection gates.

🎍

ISO 9001:2015 Certified Quality

Gulf Union Ozone is ISO 9001:2015 certified (CR 4030570569), Jeddah, Saudi Arabia. MTC verification on goods receipt, lot control, and segregation preventing material mix-ups on every instrumentation tube fitting shipment.

🗺

Nationwide KSA Delivery

Delivery to all 18 Saudi regions — Jubail, Yanbu, Dammam, Riyadh, Jizan, Ras Tanura, Al Khobar, and beyond. Project instrumentation packages and bulk spares orders fulfilled with consistent lot traceability across the Kingdom.
